Fairfield 80 Series Vinyl Windows

Fairfield 80 logo

Innovations in Window Technology

When you choose Fairfield 80 Series Windows from Alside, you’ll enjoy beauty, performance and strength. Fairfield 80 Series Windows deliver energy-saving innovations while lending the perfect touch of elegance to your home. Using the latest technology, Fairfield Windows precision-welded frame and sashes along with a 1″ thick insulated glass unit with optimal air space improves year-round performance. Our innovative ClimaTech PriME glass package meets ENERGY STAR Most Efficient criteria and may help homeowners qualify for tax credits.

This product is available in our Western distribution area.

Precision Built From The Inside Out

Fairfield 80 Windows

Leave it to Fairfield 80 Series Windows to combine energy-saving innovations with superior strength, contemporary style, carefree upkeep and excellent value.

Features

Premium vinyl won’t chip, peel, crack or warp; never needs to be painted.
Multi-chambered extrusions for superior welding strength and thermal efficiency.
1″ thick (nominal) insulated glass unit for year- round energy savings; double-strength glass optional.
Intercept Warm-Edge Spacer protects against energy loss.
Interlock at sash locking rail increases strength.
Metal-reinforced locking rail ensures durability.
Fully extruded dual lift rails for easy sash operation.
Drop-in exterior glazing provides enhanced performance during inclement weather.
Full capture sill enhances protection from air and water infiltration.
Hidden screen track for a sleek, clean appearance.
Nailing fin welded at all corners for weathertight installations

Additional Features

Heavy-duty fusion-welded mainframe and sash.
3-3/8″ frame depth for multiple applications.
Sash operates on two concealed, pre-calibrated block and tackle sash balances.
Double-pile weatherstripping helps block energy loss.
Side-load bottom sash for convenient cleaning access.
Covered weep holes allow water drainage to the exterior and prevent water or debris from coming in.
Water management system with offset drainage to the exterior.

Frame Configuration

Fairfield 80 Series Windows come standard with a 1-3/8″ nail fin. For enhanced appearance and ease of installation, three additional options are also available.


1-3/8″ Nail Fin (standard)	1″ Set Back Nail Fin	Stucco Fin

Optional PAL Locking System

Optional PAL lock (shown locked and unlocked) makes it easy to close and lock the window in a single motion.

Optional ADA compliant PAL lock (shown locked and unlocked) with an adjustable pull cord to disengage the lock.

Insulating Glass Packages

Reducing energy loss is often the number one reason for purchasing replacement windows. Windows are roughly 80% glass, so it’s important to choose the ideal glass system for your home and climate. Upgrading to a high-performance Low-E (low-emissivity) insulated glass package may help further increase year-round energy savings.

Alside offers a variety of ENERGY STAR®-certified products. Consult your window professional for an energy-efficient glass package for your home and climate zone.

ClimaTech Glass Packages

Mezzo offers four families of high-performance insulated glass packages, including our innovative ClimaTech PriME insulated glass package, which meets ENERGY STAR Most Efficient in all climate zones:

ClimaTech PriME – Combines three panes of glass, three surfaces of Low-E (low-emissivity) technology, two spaces of argon gas fill and two warm-edge spacer systems.

ClimaTech – combines insulating Low-E glass, argon gas and the Intercept Warm-Edge Spacer System.

ClimaTech ThermD – features insulating Low-E glass, argon gas and a Stainless Steel Intercept® Warm-Edge Spacer System.

ClimaTech TG2 – combines a triple-glazed unit with the Stainless Steel Intercept® Warm-Edge Spacer System, two surfaces of
low-emissivity (Low-E) glass and two airspaces filled with argon gas.

Learn more about ClimaTech Glass Packages

Sliding Windows

Fairfield 80 Sliding Window

Available in 2- and 3-lite styles, Fairfield 80 Series Sliding Windows feature a generous glass area that offers a great outdoor view. Distinctive for their smooth horizontal gliding action, sliding windows also feature sashes that lift out for easy cleaning.3

Fusion-welded mainframe and sashes for increased strength and a clean, low-profile finished look.
Multi-walled extrusions provide superb structural integrity.
Integral pull handle for easy opening and closing of the window.
Integral full-length interlock with double-pile weatherstripping increases strength and thermal performance.
Specially designed brass tandem roller system ensures smooth operation.
Cam lock and keeper for a tight seal and increased energy efficiency.

Picture, Fixed-Lite and Specialty Shape Windows

Fairfield 80 Picture Window

Paired with a beautiful outdoor view and an infusion of natural light, large picture windows can transform your home by creating a spacious and airy ambiance. Add specialty shape windows and fixed-lites to expand your window design.

Fusion-welded mainframe for increased strength and a clean, low-profile finished look.
Multi-walled extrusions provide superb structural integrity.
1-1/8″ wide nailing fin is welded in all four corners to ensure weathertight performance.
1″ thick (nominal) insulated glass with warm-edge technology for year-round energy savings.
Narrow sight-lines create a clear, expanded view.
Combine specialty shape windows and fixed-lites for a custom design.

shapes

Single Hung Windows

Fairfield 80 Series Single Hung window

With simplicity and ease, Fairfield 80 Series Single-Hung Windows will beautify and protect your home. The classic elegance of single-hung windows complements a variety of architectural styles – from contemporary to rustic.

Fusion-welded mainframe and sashes for increased strength and a clean, low-profile finished look.
Multi-walled extrusions provide superb structural integrity.
1″ thick (nominal) insulated glass with warm-edge technology for energy savings.
Side load sash operates on two concealed, pre-calibrated sash balances.
Integral lift rails ensure easy raising and lowering of the sash.
Cam lock and keeper for a tight seal and energy efficiency.
Full weatherstripping on the perimeter provides greater energy savings.

Casement Windows

Fairfield 80 Casement

Fairfield 80 Series Casement Windows feature an easy-touch crank handle for a gentle outward opening of the sash. Combining casements with fixed-lites will customize your window design with character and charm.

An easy-to-operate, heavy-duty positive crank mechanism ensures smooth opening and closing of the sash.
Stainless steel hardware delivers years of trouble-free hinge operation.
Multi-walled extrusions provide superb strength, durability and structural integrity.
An energy-efficient design with double compression bulb seal helps protect against air and water infiltration.
Multiple lite configurations are available in a single mainframe.

Awning Windows

awning window

Add a distinctive touch of style to your home with Fairfield 80 Series Awning Windows. Opening up and outward with a convenient crank handle, awning windows enhance any room with natural light and refreshing ventilation.

Fusion-welded mainframe and sashes for increased strength and a clean, low-profile finished look.
Heavy-duty, state-of-the-art hinge system provides easy opening and closing of the sash.
A dual locking system on each side of the window offers added comfort.
Combine with fixed lites to allow for convenient ventilation while creating a larger window design.
Multiple lite configurations are available in a single mainframe.

Sliding Patio Doors

Fairfield 80 Sliding Patio Door

With their pristine appearance, Fairfield 80 Series Sliding Patio Doors will create a stylish entry for your home. A well-built patio door invites the beauty of outdoors inside, while providing an energy-efficient barrier against inclement weather.

Fusion-welded construction delivers long-lasting durability.
Sturdy 4-1/2″ frame depth and 1″ wide integral nailing fin with 1-3/8″ set back for added structural integrity.
Stucco fin option is also available.
1″ thick (nominal) insulated glass with warm-edge technology provides all-weather protection.
Adjustable dual tandem roller system on an aluminum track ensures easy gliding action.
Keyed handle lock and foot lock options.
Two-, three- and four-panel configurations available.

patio door configurations

Add Your Personal Touch

Fairfield 80 Series Windows are offered in White, Almond and Desert Clay with solid color formulated throughout. Black, Architectural Bronze and Silver high-performance exterior finishes are available with a White or Almond interior only.
